Chapter - 4 : Bitwise Operators

#1 "&" Bitwise AND

It performs the AND operation on the binary equivalent of the given operands and return 1 where both the operands are 1. Try it by checking the following numbers in the terminal 5 & 6

#2 "|" Bitwise OR

It performs the OR operation on the binary equivalent of the given operands and return 1 if any of the operand is 1. Try it by checking the following numbers in the terminal 5 | 7

#3 "~" Bitwise NOT

It inverts the bits of the operands i.e. returns 1 where it was 0 and 0 where it was 1 Try it by checking the following numbers in the terminal ~5

Note : Bitwise not of any operand x results in the output of -(x+1).

#4 "^" Bitwise XOR

It perfroms the XOR operations on the bits that is the operand will return 1 when one of the two operand is 1 and returns 0 if both the operands are either 1 or 0 Try it by checking the following numbers in the terminal 2 ^ 5

#5 "<<" Bitwise Left Shift

This operator is used to shift the first operand to the left and replacing the digits by 0 to the amount specified by the value of second operand.
For example : 5 << 2 i.e.
101 << 2 Output : 10100
Try it by checking the following numbers in the terminal 7 << 2

#6 ">>" Bitwise Right Shift

This operator is used to shift the first operand to the right and replacing the digits by 0 to the amount specified by the value of second operand.
For example : 5 >> 2 i.e.
00101 >> 2 Output : 00001
Try it by checking the following numbers in the terminal 7 >> 2

#7 ">>>" Bitwise Right Shift with Zero

This operator is used to shift the first operand to the right and replacing the digits by 0 to the amount specified by the value of second operand.However it will always return a non-negative number because the sign is not preserved.
For example : 5 >>> 2 i.e.
00101 >>> 2 Output : 00001
Try it by checking the following numbers in the terminal 7 >>> 2
